Awnings · 270°XL Double-Pole / Gen 2.0 with light
XRF27XL-22 270°XL Double-Pole Fan-Shaped (With Light, 2nd Gen.)
Model XRF27XL-22 / XRF27XL-225|XL shade footprint
XL coverage on the 2nd-gen plum-blossom frame — more shade, same two-leg setup.
The XL version of our 2nd-generation 270° awning. Same custom plum-blossom poles with 1.2 mm wall and the same anti-detachment aluminium LED strip, scaled up for a larger shade footprint over bigger 4x4s, utes and trailers. 600D Oxford canopy, aluminium alloy double poles, two adjustable support legs to 2.5 m, 1000D PVC outer cover, stainless steel top pin. Available in 2 m (XRF27XL-22) and 2.5 m (XRF27XL-225).
- XL shade footprint
- 600D Oxford fabric canopy
- Anti-detachment aluminium LED light strip
- Custom plum-blossom poles, 1.2 mm wall
- Only 2 adjustable support poles
- 2 m and 2.5 m sizes, 6 in-stock colours
Features
Engineered, not assembled.
XL Fan Geometry
A larger 270° sweep than the standard model — more usable shade for full-size 4x4s, dual-cab utes and trailers.
Plum-Blossom Profile Poles
Custom-extruded plum-blossom section, 1.2 mm wall, holding the extra span without added flex.
Anti-Detachment LED Strip
Aluminium-housed LED locked into the arm channel — it stays put on corrugations.
Two-Leg Setup
Two adjustable plum-blossom support legs to 2.5 m keep pitching fast despite the larger canopy.
Stainless Steel Top Pin
Stainless pivot hardware for a hinge that stays smooth after seasons of dust and salt.
Specifications
Technical data.
Materials & construction
- Canopy: 600D Oxford fabric
- Frame: Aluminium alloy double poles
- Support poles: Plum-blossom profile, 1.2 mm wall, adjustable to 2.5 m
- Lighting: Anti-detachment aluminium LED strip
- Outer cover: 1000D PVC
- Hardware: Stainless steel top pin
Customisation options
Colour / Finish: Olive green
Final colour, trim and private-label branding confirmed at order — MOQ and lead-time on request.
Technical Details
Hover a component to explore the build.
The XL 2nd-generation awning — bigger fan, same plum-blossom frame, same anti-detachment LED strip, still a two-leg pitch.
Feature 1 of 7
XL Fan Geometry
A wider 270° sweep for full-size 4x4s, dual-cab utes and trailers that need more covered ground.
Dimensions & Specs
Numbers you can plan around.
- Generation2.0 XL (with light)
- ModelXRF27XL-22 (2 m) / XRF27XL-225 (2.5 m)
- Fabric600D Oxford
- LightingAnti-detachment aluminium LED strip
- Support poles2 adjustable, 1.2 mm wall, to 2.5 m
- Outer cover1000D PVC
- Packing (2 m)219 × 27 × 23 cm
- Weight (2 m)26.48 kg N.W. / 29.16 kg G.W.
- Packing (2.5 m)268 × 21 × 23 cm
- Weight (2.5 m)30.56 kg N.W. / 33.88 kg G.W.
Pricing
Pick a model, get a quick quote.
Prices in USD, EXW, excluding tax and freight. Volume discounts apply — send your quantity for a formal quotation.
| Select | Model | Size | Packed size | N.W. / G.W. | Price / unit |
|---|---|---|---|---|---|
| XRF27XL-22 | 2.0 m | 219 × 27 × 23 cm | 26.48 / 29.16 kg | $305 | |
| XRF27XL-225 | 2.5 m | 268 × 21 × 23 cm | 30.56 / 33.88 kg | $343 |
EXW price per unit. MOQ 20 pcs per model, samples welcome. Volume pricing and freight quoted with your order.
Choose your colour
Standard stock colours. Custom colourways available for OEM and ODM orders.
Add customisation
Tick what you need and send it straight to our team. Fees are confirmed with your quotation.
XRF27XL-22 · 2.0 m · Olive green · 20 pcs
$305 × 20 = $6,100 USD
$6,100 USD
Indicative only. EXW, excluding tax, freight and customisation fees. We confirm the final price in your quotation.
Inquiry
Get pricing for XRF27XL-22.
B2B only. We'll respond within 24 hours with wholesale pricing, MOQ and freight estimates to your port.
